What are the differences between PP / PE / PA three different types of plastic corrugated pipe?

What are the differences between PP / PE / PA three different types of plastic corrugated pipe?
     Plastic corrugated pipe are generally extruded in three materials: PP / PE / PA. Plastic corrugated pipe are excellent wire harness corrugated pipe. They have both rigidity and flexibility. They have sufficient mechanical properties and excellent flexibility. Compared with plate type The corrugated pipe per unit length have light weight, material saving, energy consumption reduction, low price, strong chemical resistance, and can withstand the influence of the acid and alkali in the surrounding environment. Increase its flexibility to facilitate continuous laying on uneven objects; convenient interface and good sealing performance, easy to handle, easy to install, reduce labor intensity, shorten the construction period, wide temperature range, flame retardant, self-extinguishing, safe use It has good electrical insulation performance and is an ideal material for wire bushings.

      Plastic corrugated pipe is used for the sheathing of wire harnesses of automobiles, motorcycles and other motor vehicles, and can also be used for the sheathing of wire harnesses of household appliances, precision machine tools and other equipment; it has good stability for various animal and vegetable oils and mineral oils ; Can withstand various concentrations of alkali. Plastic corrugated pipe is an ideal material for making wire sleeves. It is light in texture and very convenient to use. In addition to being used for wire and cable sleeves, it is widely used in many aspects.

     PE (polyethylene) plastic corrugated pipe

     No oxidizing acid, no animal, vegetable oil, mineral oil environment; no aliphatic hydrocarbons, aromatic hydrocarbons, ketones, esters and other organic solvents.

It is mainly used in the temperature range of -40 ~ 80 ℃; used in the sheath of wire harnesses of automobiles, motorcycles and other motor vehicles; also used in the sheath of wire harnesses of household appliances, precision machine tools and other equipment.

     PP (polypropylene) plastic corrugated pipe

      In the environment without strong acid and high concentration of oxidant; soluble in aromatic hydrocarbons and chlorinated hydrocarbons such as benzene and toluene in an environment of ≥80 ℃; stable to most oils, absorbing a small amount of mineral oil and vegetable oil.

     Mainly used in the temperature range of -20 ~ 120 ℃; used in the sheath of wire harnesses of automobiles, motorcycles and other motor vehicles; also used in the sheath of wire harnesses of household appliances, precision machine tools and other equipment.

      PA6 (nylon 6) corrugated pipe

     Free from sulfuric acid, formic acid, acetic acid, nitric acid, hydrochloric acid, calcium chloride, methanol and strong oxidants; soluble in ethylene glycol, glacial acetic acid, chloroethanol, propylene glycol, 1,5 pentanediol, trichloroethylene at high temperature , Methanol solution of zinc chloride, phenol, cresol and other solvents.

     Mainly used in the environment with a temperature range of -34 ~ 140 ℃; used for the sheath of wire harnesses of automobiles, motorcycles and other motor vehicles; also used for the sheath of wire harnesses of household appliances, precision machine tools and other equipment; Animal and vegetable oils and mineral oils have good stability; they are resistant to various concentrations of alkali.
